Jellymix is a compact stereo performance mixer designed for electronic musicians. Connect your favourite synths, drum machines, modules, and grooveboxes to the five stereo input channels. Shape your sounds live with channel EQ, the dual stereo resonant filters, and stereo effects on the two stereo AUX busses. The tactile and inviting interface of Jellymix is perfect for knob twiddling, switch flicking, and/or button pushing your way to new sonic joys and dubby dreams; live on stage, your living room, or in the studio.
Features
- 5 stereo channel strips with balanced ¼” line inputs and clickless mutes
- 2 stereo balanced AUX Sends per channel (PRE/POST w/ mono sum normalling)
- 2 stereo balanced EXT inputs (summed to MAIN bus, can be used as AUX Returns)
- Hi-Z Instrument input on channel one (for connecting guitars, etc.)
- Stereo SVF master filters with separate LO CUT (HPF) and HI CUT (LPF) controls, dedicated resonance knob (Q), and clickless bypass switches.
- Main output level control with led meter
- Headphone output with selectable source (MAIN or MUTED bus)
- Pleasing overdrive via soft clipping on all critical stages of the audio paths: channel gains/sums, EQ, aux busses, filter bus, and main output bus
- All analog design with high-quality and durable construction: Neutrik jacks, Alpha pots, Salecom sealed switches, Sound Semiconductor VCAs, and Low-noise/Low-distortion op-amps
Specifications
- Dimensions: 277mm x 122mm x 66mm / 10.9″ x 4.8″ x 2.6″
- DC Power Supply included (Meanwell 30W/12Vx2.5A)
