Function summoning goodness for the Eurorack temporal plane from dark lords, Ritual Electronics..
Anima is a dual voltage-controlled segments generator. It can be an AD or an ASR enveloppe, an LFO, a Digital Oscillator and even more. Breath life into your modular patches with continuously evolving sonic modulations. The 1V/Oct input turns Anima into a very capable digital dual oscillator.
Anima has three basic modes of operation:
- AD, the module takes any signal as an input, turns it into a trigger to launch a rising segment (attack) and a falling segment (decay).
- ASR, the module takes any signal as an input and turns it into a gate.
- Cycle does not rely on an incoming signal. It loops the rising and falling segments according to their lengths.
For maximum versatility each channel of Anima has an output polarity switch, making it 0 to +8V in unipolar mode or -5 to 5V in bipolar mode, suitable for audio or bipolar CV generation.
Specifications
Width: 18hp
Depth: 25mm
Power: +12V: 95mA | -12V: 32mA
